Sinolift ND99S Walkie-Type Lithium Cell Reel Truck

Name: Sinolift ND99S WalkieType Lithium Cell Reel Truck
Brand: SINOLIFT
Price: 1 USD

China Sinolift ND99S Walkie-Type Lithium Cell Reel Truck wholesale

Brand Name : SINOLIFT

Model Number : ND99S

Certification : CE

Place of Origin : CHINA

MOQ : 1 set

Price : Negotiable

Payment Terms : L/C, D/A, D/P, T/T

Supply Ability : 1000 sets/mouth

Delivery Time : 15 days

Packaging Details : Sandard Export Package

Product name : Sinolift ND99S Walkie-Type Lithium Cell Reel Truck

Driving style : Pedestrian

Rated Load : 1000kg

Net weight : 730kg

Warranty : 1 year

After service : on-line service,free spare parts

Contact Now

Product Name

Sinolift ND99S Walkie-Type Lithium Cell Reel Truck

The ND99S Walkie-Type Lithium Cell Reel Truck is a versatile material handling solution for the lithium battery industry, film rolls, and paper rolls. With a load capacity of up to 1.0 tons, dual electric/semi-electric modes, and intelligent push-pull operation, it ensures fast, stable, and safe lifting. Designed for easy one-person operation, narrow spaces, and efficient loading/unloading.

Product Specifications

Model		ND99S1	ND9952
Drive Type		Hydraulic	Hydraulic
Rated Load	kg	1000	1000
Load Center	mm	650	650
Minimum Height	mm	650	650
Maximum Height	mm	1960	1960
Overall Length	mm	1496	1496
Overall Width	mm	780	780
Overall Height	mm	2200	2200
Cantilever Specification	mm	Ø295*720	Ø395*720
Front Wheel Specification	mm	Ø80-70	Ø80-70
Rear Wheel Specification	mm	Ø205X75	205X75
Lifting Motor	kw	DC24V/1.2	DC24V/1.2
Driving Motor	kw	DC24/0.75	DC24/0.75
Power Supply Specification	V/Ah	DC24/125AH	DC24/125AH
Battery Type		Lithium Iron Phosphate (LiFePO₄)	Lithium Iron Phosphate (LiFePO₄)
Drive Control Type		DC Speed Control	DC Speed Control
Noise Level	Db	≤70	≤70
Steering Type		Mechanical Steering	Mechanical Steering
Braking Mode		Electromagnetic Brake	Electromagnetic Brake
Net Weight	kg	730	740
Lifting Speed	mm/s	103	103
Side Shift Mechanism		Ball Screw	Ball Screw
Side Shift Motor	Kw	DC24V/0.4	DC24V/0.4

Sinolift ND99S Walkie-Type Lithium Cell Reel Truck

Sinolift ND99S Walkie-Type Lithium Cell Reel Truck Images
